Description
The balancing valve is designed for hydraulic balancing, regulation and limitation of the flow of the working medium in heating and cooling systems. The valve can effectively solve the problem of uneven distribution of temperature and heat in the heating system. At the same time, the balancing valve will allow you to accurately adjust the pressure drop and flow rate for accurate balancing of the working medium in the pipeline network system.
Overall dimensions of the socket balancing valve DNOVA VB0000P-T PN16 brass
| DN | L | Weight |
| mm | kg | |
| 15 | 76 | 0.36 |
| 20 | 80 | 0.415 |
| 25 | 88 | 0.54 |
| 32 | 95 | 0.73 |
| 40 | 105 | 0.98 |
| 50 | 118 | 1.47 |
Sketch of coupling balancing valve DNOVA VB0000P-T PN16 brass, Threaded connection
Materials of parts of the socket balancing valve DNOVA VB0000P-T PN16 brass, Threaded connection
| № | Name | Quantity | Material |
| 1 | Pressure plate gasket | 1 | PTFE |
| 2 | Washer | 1 | PTFE |
| 3 | Pressure plate | 1 | Brass |
| 4 | Plug | 1 | Brass |
| 5 | Valve stem | 1 | Brass |
| 6 | Spindle | 1 | Brass |
| 7 | Setting blocker | 1 | Brass |
| 8, 9 | O-ring - black | 3 | EPDM |
| 10 | locking ring | 1 | 15XM steel |
| 11 | Body | 1 | Brass |
| 12 | Exhaust valve locking cap | 2 | Brass |
| 13 | O-ring gasket | 2 | EPDM |
| 14 | Measuring nipple | 2 | Brass |
| 15 | Blue connecting tape | 1 | EPDM |
| 16 | Nipple cover | 2 | Brass |
| 17 | Cover gasket | 2 | EPDM |
| 18 | Red connecting tape | 1 | EPDM |
| 19 | Stop screw | 1 | Brass |
| 20 | Flywheel plug | 1 | PA66 plastic |
| 21 | Flywheel | 1 | PA66 plastic |
Detailed sketch of socket balancing valve DNOVA PN16 brass, Threaded connection
