Spring check valve DNOVA VCS3232P-T, body material - stainless steel AISI 316, closure element material - stainless steel AISI 316, seal - PTFE

From $2.19 USD
From $2.19 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
View full details

Description

Check valve is a device in a pipeline that allows fluids or gases to flow in only one direction. When the pressure of the fluid or gas in the pipeline exceeds a certain value, the valve opens, allowing the substance to pass through. However, when the pressure drops or tries to move in the opposite direction, the valve closes, preventing backflow. Check valves are widely used in various industrial and commercial applications to ensure safety and control the flow in pipeline systems.





 Dimensions of the spring check valve DNOVA VCS3232P-T, body material - stainless steel AISI 316

 Sketch of spring check valve DNOVA VCS3232P-T, body material - stainless steel AISI 316, closure element material - stainless steel AISI 316, seal - PTFE

DN D L Weight
mm kg
15 14 61 0.1
20 20 65 0.2
25 25 78 0.3
32 32 88 0.5
40 36 100 0.6
50 50 110 1



 Spring check valve specification DNOVA VCS3232P-T, body material - stainless steel AISI 316

 Material sketch of spring check valve DNOVA VCS3232P-T, body material - stainless steel AISI 316, closure element material - stainless steel AISI 316, seal - PTFE

№ Part name Material
1,3 Body CF8/CF8M steel
2 Gasket PTFE
4 Disk steel SS304 / SS316
5 Spring steel SS304 / SS316

Specifications

Country of origin
China
Body material
Stainless steel AISI 316
Maximum allowable temperature
230 °C
Connection type
Threaded NPT/BSP
Operating environment
Water, Air, Oil Products
Applications
Water Supply
Nominal pressure
16 bar
Type of seal
PTFE
Locking material
Stainless steel AISI 316/1.4401
Check valve type
Spring
