Description
Knife gate valves are a specific type of gate valve that are typically used in industries for handling tough solids and slurries. Named for their shape, knife gate valves have a sharp, knife-like gate that can cut through viscous or solid material in the flow. They are commonly used in wastewater treatment plants, paper mills, mining operations, and food industries, among others. Their primary function is to start or sop a flow or adjust its volume, but they do not control the pressure or flow rate.
Overall and installation dimensions of the gate valve DNOVA GVKN1331N-2W-Fb-R, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, gear operated
| DN | PN | L | D | D1 | D2 | D0 | H1 | d | T | N | M | Weight |
| 400 | 6 | 90 | 565 | 515 | 480 | 350 | 970 | 27 | 24 | 16 | M24 | 90 |
| 500 | 4 | 105 | 670 | 620 | 582 | 310 | 1200 | 27 | 24 | 20 | M24 | 192 |
| 600 | 4 | 125 | 780 | 725 | 682 | 310 | 1410 | 30 | 27 | 20 | M27 | 252 |
Valve sketch DNOVA GVKN1331N-2W-Fb-R, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, gear operated
Construction and materials of the gate DNOVA GVKN1331N-2W-Fb-R, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, gear operated
| № | Part name | Material |
| 1 | O-ring | Nitrile NBR |
| 2 | Gate valve body | Cast iron GGG40 |
| 3 | Disk seal | Nitrile NBR |
| 4 | Disk | steel AISI304 |
| 5 | Bolt | steel AISI201 |
| 6 | Gland packing | PTFE |
| 7 | Bolt and nut | steel AISI201 |
| 8 | gland | Carbon steel WCB |
| 9 | Bolt and nut | steel AISI201 |
| 10 | Nut | Brass |
| 11 | Stem | steel 2Cr13 |
| 12 | Support plates | steel A3 |
| 13 | Bolt | steel A3 |
| 14 | Bearing cover | Carbon steel WCB |
| 15 | Bearing | ZChSnSb10-6 |
| 16 | Gearbox | Cast iron GGG40 |
Material sketch of valve parts DNOVA GVKN1331N-2W-Fb-R, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, gear operated
Specifications
Delivery
The cost and delivery time for your order depend on several factors, including the specific product you are ordering, the quantity, and the country of destination. Each product may have different manufacturing lead times and shipping requirements, which can affect the overall delivery schedule.
To get the most accurate and up-to-date information on delivery costs and timelines, we recommend contacting our sales managers. They will be happy to provide you with a detailed quote and estimated delivery time based on your specific requirements.
Please feel free to reach out to us for any questions or further assistance regarding your order.
