Description
Knife gate valves are a specific type of gate valve that are typically used in industries for handling tough solids and slurries. Named for their shape, knife gate valves have a sharp, knife-like gate that can cut through viscous or solid material in the flow. They are commonly used in wastewater treatment plants, paper mills, mining operations, and food industries, among others. Their primary function is to start or sop a flow or adjust its volume, but they do not control the pressure or flow rate.
Overall and installation dimensions of the gate valve DNOVA GVKR1331N-2W-Fb-S, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, handwheel operated
| DN | PN | L | D | D1 | D2 | D0 | N-Th | d | H | H2 | Weight, kg |
| 50 | 10 | 50 | 165 | 125 | 99 | 180 | 4-M16 | Ø18 | 290 | 96 | 8 |
| 65 | 10 | 50 | 185 | 145 | 118 | 180 | 4-M16 | Ø18 | 320 | 96 | 9 |
| 80 | 10 | 50 | 200 | 160 | 132 | 220 | 4-M16 | Ø18 | 350 | 103 | 13 |
| 100 | 10 | 50 | 220 | 180 | 156 | 240 | 4-M16 | Ø18 | 385 | 129 | 14 |
| 125 | 10 | 50 | 250 | 210 | 184 | 240 | 4-M16 | Ø18 | 430 | - | 18 |
| 150 | 10 | 62 | 285 | 240 | 211 | 280 | 8-M20 | Ø23 | 485 | 183 | 24 |
| 200 | 10 | 62 | 340 | 295 | 266 | 300 | 12-M20 | Ø23 | 565 | 234 | 31 |
| 250 | 10 | 70 | 405 | 355 | 319 | 320 | 12-M24 | Ø27 | 680 | 283 | 48 |
| 300 | 10 | 80 | 460 | 400 | 370 | 320 | 12-M24 | Ø27 | 755 | 330 | 63 |
Valve sketch DNOVA GVKR1331N-2W-Fb-S, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, handwheel operated
Construction and materials of the gate DNOVA GVKR1331N-2W-Fb-S, body material - cast iron GGG40, knife material - stainless steel AISI 304, seal - NBR, handwheel operated
| № | Part name | Material |
| 1 | Body | Cast iron GGG40 |
| 2 | Seat seal | NBR nitrile |
| 3 | Knife | AISI304 steel |
| 4 | gland | Ductile iron |
| 5 | Support plates | Carbon steel |
| 6 | Stem | Cast iron |
