Description
An electric solenoid valve is a type of valve that uses an electromagnetic solenoid coil to control the flow of fluids or gases. When an electric current is applied to the solenoid coil, it generates a magnetic field that moves a plunger or a valve stem, allowing or stopping the flow of the fluid through the valve. Electric solenoid valves are commonly used in various applications such as irrigation systems, HVAC (heating, ventilation, and air conditioning) systems, industrial automation, and control systems, where remote control of fluid flow is necessary.
В
В
Main technical data and characteristicsВ
| Parameter | Value |
|---|---|
| Nominal diameter, DN | 6–50 |
| Nominal pressure, bar | 10 |
| Operating pressure, bar | 0–7 |
| Working medium | Air, light oil, water |
| Medium temperature, В°C | NBR: from -5 to +80; VITON: from -10 to +150; EPDM: from -5 to +90 |
| Ambient temperature, В°C | from -5 to +80 |
| Seal material | NBR, VITON, EPDM |
| Connection | Threaded |
| Body material | Brass or stainless steel AISI 304 |
| Valve type | Direct-acting |
| Coil shape | VS2W-100/VS2W-101 – cylindrical; VS2W-300/VS2W-301 – cubic |
| Coil supply voltage, V | 220VAC – AC 220V; 24VDC – DC 24V; 24VAC – AC 24V |
| Valve configuration | VS2W-100/VS2W-101 – normally closed; VS2W-300/VS2W-301 – normally closed / normally open |
| Kinematic viscosity of medium | <20 CST |
| Average service life (cycles) | 600,000 (with non-aggressive medium and average pressure and temperature conditions) |
В
В
Dimensions and installation dimensions of solenoid valves DNOVA VS231-VT-NC-220VAC-DA
| DN | F | A | B | C | Weight, kg |
| 15 | 1/2" | 92 | 55 | 100 | 0.74 |
| 20 | 3/4" | 95 | 55 | 106 | 0.8 |
| 25 | 1" | 105 | 78 | 115 | 1.36 |
В
.jpg)
Sketch of DNOVA VS231-VT-NC-220VAC-DA solenoid valve
