In detail
What it is made of
How it works
Linear electric actuator
The number that matters
Nominal pressure
25bar
The pressure class of the valve body at 20 °C. Working limits depend on the medium and its temperature.
Construction
Parts and materials
Applications
Media and industries
- Water
- Ethylene Glycol
- Neutral Media
- Propylene glycol
- Water Supply
- Heating Systems
- Ventilation
The three-way mixing/separating control valve is designed to regulate the flow of working media that are not aggressive to the materials of the regulating body by mixing or separating them. The valve is controlled by means of an electric actuator (electric actuator (EIM)). The force developed by the actuator is transmitted through the stem to the plug, which, moving up or down, changes the cross-sectional area in the gate and regulates the flow of the working medium.
Technical parameters of DNOVA VRg3M/S-31M-LED-T three-way control valves, body material - stainless steel AISI 304, locking body material - stainless steel AISI 304, seal - metal, with electric drive DAV 24V:
| Name | Significance |
| Valve type | Regulating |
| Nominal pressure PN, bar | 25 |
| Medium | water, ethylene glycol, neutral media, Propylene glycol |
| Application | Water supply, Heating systems, Ventilation |
| Working medium temperature, °C | +1 to +300 |
| Ambient temperature, °C | +1 to +50 |
| Connection type | coupling (threaded) |
| Type of control valve | three-way |
| Service life, years | 10 |
| Manufacturer's country | China |
Two-way control valve DNOVA VRg3M/S-31M-LED-T, body material - stainless steel AISI 304, locking body material - stainless steel AISI 304, seal - metal, with electric drive DAV 24V
Dimensions and dimensions DNOVA VRg3M/S-31M-LED-T three-way control valves, body material - stainless steel AISI 304, locking body material - stainless steel AISI 304, seal - metal, with electric drive DAV 24V:
| DN | 15 | 20 | 25 | 32 | 40 | 50 |
| L, mm | 85 | 85 | 90 | 105 | 120 | 140 |
| H, mm | 60 | 60 | 60 | 61 | 70,5 | 78,5 |
| H1, mm | 310 | 310 | 310 | 310 | 330 | 360 |
| Joining | G1/2” | G3/4” | G1” | G1 ¼” | G1 1/2" | G2” |
| Weight, kg (valve+EIM) | 3,0 | 3,0 | 3,1 | 3,5 | 4,1 | 4,6 |
Sketch of dimensions and dimensions DNOVA VRg3M/S-31M-LED-T, body material - stainless steel AISI 304, locking body material - stainless steel AISI 304, seal - metal, with electric drive DAV 24V
Parts and materials table DNOVA VRg3M/S-31M-LED-T three-way control valves, body material - stainless steel AISI 304, locking body material - stainless steel AISI 304, seal - metal, with electric drive DAV 24V:
| Details | Materials |
| Body | stainless steel AISI 304 |
| Rod | stainless steel AISI 304 |
| Plunger | stainless steel AISI 304 |
| Stem seal | EPDM |
| Stem guides | PTFE |
- Body material
- Stainless steel AISI 304
- Maximum allowable temperature
- 150 °C
- Connection type
- Threaded
- Control type
- electric drive
- Operating environment
- Water, Ethylene Glycol, Neutral Media, and Propylene glycol
- Applications
- Water Supply, Heating Systems, and Ventilation
- Nominal pressure
- 25 bar
- Type of seal
- Metal
- Locking material
- stainless steel AISI 304
- Manual override
- Yes
- Type of electric actuator
- Straight-through
- Supply voltage
- 24 V
- Type of control valve
- three-way
- Regulator Type
- control valve
- Country of origin
- China
Production. Usually 7–14 business days after you approve the quotation and pay. Made-to-specification items are confirmed in the quotation.
Freight. Not charged at checkout. A manager quotes air and sea freight to your port or airport, and nothing ships until you approve the price and the freight.
To North America. From approval and payment to the destination port or airport: air 14–24 days, sea 32–60 days. Estimates, not guarantees.
Terms. EXW Ningbo or FOB Ningbo Port; CIF on request. The agreed term is written on the Proforma Invoice.
